How to create a responsive hamburger navigation menu — ReactJS and Styled Components
4
Shares
Sun Jan 03 2021

How to create a responsive hamburger navigation menu — ReactJS and Styled Components

Awa Dieudonne

Awa Dieudonne

934 views

In order to build a website with a good user experience, there are a lot of things to consider and one of them is how responsive your site is going to be. Your site can be responsive and still have a bad user experience. But how do you solve this?


In this article, I am going to walk you through building a hamburger responsive navigation menu from scratch using Reactjs and Styled-Components. To do this, there are a few things to handle.


Setup React app

In your terminal, run the following scripts. Then open http://localhost:3000 to see your app.

npx create-react-app responsive-nabar
cd responsive-nabar
npm start


While your app is running, install styled components using the following scripts.

npm install styled-components


Go to your root directory and clear out the create react app files we won't be needing. Your directory structure should look exactly like this


Open your index.html and add the following code directly below the <title> tag.

<style>
  * {
    padding: 0;
    margin: 0;
    box-sizing: border-box;
  }
</style>


Update your App.js file with the following code

// App.jsx
import React from 'react';
function App() {
    return (
      <div className="App">
         App
      </div>
  );
}
export default App;


Your RightNav.jsx, Burger.jsx, and Navbar.jsx files should have the respective codes below

// App.jsx
import React from 'react';
import Navbar from './Nav/Navbar';

function App() {
  return (
    <div className="App">
      <Navbar />
      App
    </div>
  );
}

export default App;


// RightNave.jsx
import React from 'react';

const RightNav = () => {
  return (
    <ul>
      <li>Home</li>
      <li>About Us</li>
      <li>Contact Us</li>
      <li>Sign In</li>
      <li>Sign Up</li>
    </ul>
  )
}

export default RightNav


// Burger.jsx
import React, { useState } from 'react';
import styled from 'styled-components';
import RightNav from './RightNav';

const Burger = () => {
  const [open, setOpen] = useState(false)

  return (
    <React.Fragment>
      <div>
        <div />
        <div />
        <div />
      </div>
      <RightNav open={open}/>
    </React.Fragment>
  )
};

export default Burger;


// Navbar.jsx
import React from 'react';
import Burger from './Burger';

const Nav = styled.nav`
  // css goes here
`;

const Navbar = () => {
  return (
    <Nav>
      <div className="logo">
        Nav Bar
      </div>
      <Burger />
    </Nav>
  )
}

export default Navbar


After this, your app should look as shown below with no styling yet.


Let's style our navigation menu.

Given that we already install styled-components, our RightNav.jsx, Burger.jsx, and Navbar.jsx components will finally look as follows.

import React, { useState } from 'react';
import styled from 'styled-components';
import RightNav from './RightNav';

const StyledBurger = styled.div`
  width: 2rem;
  height: 2rem;
  position: fixed;
  top: 15px;
  right: 20px;
  z-index: 20;
  display: none;

  @media (max-width: 768px) {
    display: flex;
    justify-content: space-around;
    flex-flow: column nowrap;
  }

  div {
    width: 2rem;
    height: 0.25rem;
    background-color: ${({ open }) => open ? '#ccc' : '#333'};
    border-radius: 10px;
    transform-origin: 1px;
    transition: all 0.3s linear;

    &:nth-child(1) {
      transform: ${({ open }) => open ? 'rotate(45deg)' : 'rotate(0)'};
    }

    &:nth-child(2) {
      transform: ${({ open }) => open ? 'translateX(100%)' : 'translateX(0)'};
      opacity: ${({ open }) => open ? 0 : 1};
    }

    &:nth-child(3) {
      transform: ${({ open }) => open ? 'rotate(-45deg)' : 'rotate(0)'};
    }
  }
`;

const Burger = () => {
  const [open, setOpen] = useState(false)

  return (
    <>
      <StyledBurger open={open} onClick={() => setOpen(!open)}>
        <div />
        <div />
        <div />
      </StyledBurger>
      <RightNav open={open}/>
    </>
  )
}

export default Burger


import React from 'react';
import styled from 'styled-components';
import Burger from './Burger';

const Nav = styled.nav`
  width: 100%;
  height: 55px;
  border-bottom: 2px solid #f1f1f1;
  padding: 0 20px;
  display: flex;
  justify-content: space-between;

  .logo {
    padding: 15px 0;
  }
`

const Navbar = () => {
  return (
    <Nav>
      <div className="logo">
        Nav Bar
      </div>
      <Burger />
    </Nav>
  )
}

export default Navbar


import React from 'react';
import styled from 'styled-components';

const Ul = styled.ul`
  list-style: none;
  display: flex;
  flex-flow: row nowrap;

  li {
    padding: 18px 10px;
  }

  @media (max-width: 768px) {
    flex-flow: column nowrap;
    background-color: #0D2538;
    position: fixed;
    transform: ${({ open }) => open ? 'translateX(0)' : 'translateX(100%)'};
    top: 0;
    right: 0;
    height: 100vh;
    width: 300px;
    padding-top: 3.5rem;
    transition: transform 0.3s ease-in-out;

    li {
      color: #fff;
    }
  }
`;

const RightNav = ({ open }) => {
  return (
    <Ul open={open}>
      <li>Home</li>
      <li>About Us</li>
      <li>Contact Us</li>
      <li>Sign In</li>
      <li>Sign Up</li>
    </Ul>
  )
}

export default RightNav


import React, { useState } from 'react';
import styled from 'styled-components';
import RightNav from './RightNav';

const StyledBurger = styled.div`
  width: 2rem;
  height: 2rem;
  position: fixed;
  top: 15px;
  right: 20px;
  z-index: 20;
  display: none;

  @media (max-width: 768px) {
    display: flex;
    justify-content: space-around;
    flex-flow: column nowrap;
  }

  div {
    width: 2rem;
    height: 0.25rem;
    background-color: ${({ open }) => open ? '#ccc' : '#333'};
    border-radius: 10px;
    transform-origin: 1px;
    transition: all 0.3s linear;

    &:nth-child(1) {
      transform: ${({ open }) => open ? 'rotate(45deg)' : 'rotate(0)'};
    }

    &:nth-child(2) {
      transform: ${({ open }) => open ? 'translateX(100%)' : 'translateX(0)'};
      opacity: ${({ open }) => open ? 0 : 1};
    }

    &:nth-child(3) {
      transform: ${({ open }) => open ? 'rotate(-45deg)' : 'rotate(0)'};
    }
  }
`;

const Burger = () => {
  const [open, setOpen] = useState(false)

  return (
    <>
      <StyledBurger open={open} onClick={() => setOpen(!open)}>
        <div />
        <div />
        <div />
      </StyledBurger>
      <RightNav open={open}/>
    </>
  )
}

export default Burger


import React from 'react';
import styled from 'styled-components';
import Burger from './Burger';

const Nav = styled.nav`
  width: 100%;
  height: 55px;
  border-bottom: 2px solid #f1f1f1;
  padding: 0 20px;
  display: flex;
  justify-content: space-between;

  .logo {
    padding: 15px 0;
  }
`

const Navbar = () => {
  return (
    <Nav>
      <div className="logo">
        Nav Bar
      </div>
      <Burger />
    </Nav>
  )
}

export default Navbar


import React from 'react';
import styled from 'styled-components';

const Ul = styled.ul`
  list-style: none;
  display: flex;
  flex-flow: row nowrap;

  li {
    padding: 18px 10px;
  }

  @media (max-width: 768px) {
    flex-flow: column nowrap;
    background-color: #0D2538;
    position: fixed;
    transform: ${({ open }) => open ? 'translateX(0)' : 'translateX(100%)'};
    top: 0;
    right: 0;
    height: 100vh;
    width: 300px;
    padding-top: 3.5rem;
    transition: transform 0.3s ease-in-out;

    li {
      color: #fff;
    }
  }
`;

const RightNav = ({ open }) => {
  return (
    <Ul open={open}>
      <li>Home</li>
      <li>About Us</li>
      <li>Contact Us</li>
      <li>Sign In</li>
      <li>Sign Up</li>
    </Ul>
  )
}

export default RightNav


import React, { useState } from 'react';
import styled from 'styled-components';
import RightNav from './RightNav';

const StyledBurger = styled.div`
  width: 2rem;
  height: 2rem;
  position: fixed;
  top: 15px;
  right: 20px;
  z-index: 20;
  display: none;

  @media (max-width: 768px) {
    display: flex;
    justify-content: space-around;
    flex-flow: column nowrap;
  }

  div {
    width: 2rem;
    height: 0.25rem;
    background-color: ${({ open }) => open ? '#ccc' : '#333'};
    border-radius: 10px;
    transform-origin: 1px;
    transition: all 0.3s linear;

    &:nth-child(1) {
      transform: ${({ open }) => open ? 'rotate(45deg)' : 'rotate(0)'};
    }

    &:nth-child(2) {
      transform: ${({ open }) => open ? 'translateX(100%)' : 'translateX(0)'};
      opacity: ${({ open }) => open ? 0 : 1};
    }

    &:nth-child(3) {
      transform: ${({ open }) => open ? 'rotate(-45deg)' : 'rotate(0)'};
    }
  }
`;

const Burger = () => {
  const [open, setOpen] = useState(false)

  return (
    <>
      <StyledBurger open={open} onClick={() => setOpen(!open)}>
        <div />
        <div />
        <div />
      </StyledBurger>
      <RightNav open={open}/>
    </>
  )
}

export default Burger


import React from 'react';
import styled from 'styled-components';
import Burger from './Burger';

const Nav = styled.nav`
  width: 100%;
  height: 55px;
  border-bottom: 2px solid #f1f1f1;
  padding: 0 20px;
  display: flex;
  justify-content: space-between;

  .logo {
    padding: 15px 0;
  }
`

const Navbar = () => {
  return (
    <Nav>
      <div className="logo">
        Nav Bar
      </div>
      <Burger />
    </Nav>
  )
}

export default Navbar


import React from 'react';
import styled from 'styled-components';

const Ul = styled.ul`
  list-style: none;
  display: flex;
  flex-flow: row nowrap;

  li {
    padding: 18px 10px;
  }

  @media (max-width: 768px) {
    flex-flow: column nowrap;
    background-color: #0D2538;
    position: fixed;
    transform: ${({ open }) => open ? 'translateX(0)' : 'translateX(100%)'};
    top: 0;
    right: 0;
    height: 100vh;
    width: 300px;
    padding-top: 3.5rem;
    transition: transform 0.3s ease-in-out;

    li {
      color: #fff;
    }
  }
`;

const RightNav = ({ open }) => {
  return (
    <Ul open={open}>
      <li>Home</li>
      <li>About Us</li>
      <li>Contact Us</li>
      <li>Sign In</li>
      <li>Sign Up</li>
    </Ul>
  )
}

export default RightNav


You can now check your app on the browser and it should look like this

Conclusion

Finally, you should have a responsive navigation menu with some nice hamburger animations when clicked. In case you face any problems, you can reference the repository on GitHub. Or, leave a comment in the comment section and I will reply ASAP..

Thanks

ReactJSStyled-components
